| Supply Voltage |
10 - 16 Volts CC |
| Working temperature |
-20 / + 105 °C |
| Power consumption |
- |
| Stand-by (key Off) |
< 20 mA |
| No load ready to change (key On) |
< 160 mA |
| Gas Injectors supported |
2, 3, 4 |
| Injectors Impedance |
From 2 to 16 ohms |
| Lock-off load on single input |
2 (Imax = 4A cad.) |
| Inputs for lock-off / Services |
2 |
| Water temper. sensors supported |
4,7 - 10 kohm |
| Gas temper. sensors supported: |
4,7 - 10 kohm |
| Pressure sensors supported |
4+2,5 bar Absolute |
| Level sensors supported |
1050 & 806 compatibles, 0-90 ohm (others on demand) |
| Lambda sensors managed |
0-0,8 / 0-5 / 5-0 / 0,8-1,6 / 2,5-3,5 / UEGO |
| Lambda emulation |
Possible for all managed types |
| Change-over Switch |
Pushbutton, gas level shown, operating led,ready-to-change blinking, diagnostics, Buzzer |
| Interface |
4 poles AMP on the loom for custom USB or Bluetooth interface |
| Standard OBD protocols supported |
ISO 9141-2
KEYWORD 2000
(5 BAUD and INIT FAST)
CAN STANDARD 250 & 500
CAN EXTENDED 250 & 500 |
